YEAPHI 800W 1000W 36V 48V 3000rpm ElectroCraft Brushless DC Motors bldc motor for electric vehicle walking mower

    • YEAPHI 800W 1000W 36V 48V 3000rpm brushless DC blade motor controller is used for walking mower. It has H level insulation and flexible operation.
  • application (1)
  • application (2)
  • application (3)
  • application-(2)
  • application-(3)
mailCONTACT NOW pdfpdf Download

We provide you with

  • Free customized development.

  • Professional service-YEAPHI

    has 3 research and development centers that solve customers' technical challenges.

  • Excellent cost control

    based on high self-manufactured ratio.

  • Full compliance

    with IATF16949 standards.

  • Over 5 years' experience

    in electric lawn vehicle based on cooperating with RYOBI and Greenworks.

  • Products catalogue

    ● 800W-5KW blade controller.
    ● 800W-5KW blade motor.
    ● 800W-5KW driving controller.
    ● 800W-5KW driving motor.
    ● 1KW-1.2KW driving train including driving motor, gearbox and brake.
    ● Angle sensor.

Product features

  • 01

    Electric parameters

      • Power: 800W-1000W.
      • Voltage: 36V-40V.
      • Torque: 2.55N.m.
      • Rated speed: 3000rpm.
      • Working method: S1.
      • IP level: IP65.
      • Insulation level: H.
      • Rotation: The motor rotates unidirectional.
      • Leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S,leak current ≤3mA.
  • 02

    Merits

      • Stable performance-The 800W-1000W motor has over 4 years of production and its performance is very stable.
      • Small size -Due to the rotor is a permanent magnet, no special field windings are required and the motor is smaller at the same capacity.
      • Comfortable operation experience-The motor with a respond rate which brings a pleasing operating experience.
      • Adjustable-Programmable hall sensor which approve the motor can be customized.
      • Highly recognized by the market-After years of testing, the products gained good feedback from the market.
      • Compared with traditional garden tools, the new lithium electric cutting motor has higher durability.
      • Strong applicability-Because of the programmable software, the products can suit for different application scenario.
  • 03

    Application

      • Electric walking mower.

Specifications

Power Voltage Torque Rated speed IP Level Working method
800W/1000KW 36V-40V 2.52N.m 3000rpm IP65 S1

Product Advantages

1. The motor is unidirectional rotation.
2. Insulation level:H.
3. leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S, leak current ≤3mA.
  • pro_service

    Electric parameters

    ►Power: 800W-1000W.
    ►Voltage: 36V-40V.
    ►Torque: 2.55N.m.
    ►Rated speed: 3000rpm.
    ►Working method: S1.
    ►IP level: IP65.
    ►Insulation level: H.
    ►Rotation: The motor rotates unidirectional.
    ►leak current: Applied AC voltage between windingand iron core 1.8±0.1KV/3S,leak current ≤3mA.

  • pro_service

    Merits

    ►Stable performance-The 800W-1000W motor has over 4 years of production and its performance is very stable.
    ►Small size -Due to the rotor is a permanent magnet, no special field windings are required and the motor is smaller at the same capacity.
    ►Comfortable operation experience-The motor with a respond rate which brings a pleasing operating experience.
    ►Adjustable-Programmable hall sensor which approve the motor can be customized.
    ►Highly recognized by the market-After years of testing, the products gained good feedback from the market.
    ►Compared with traditional garden tools, the new lithium electric cutting motor has higher durability.
    ►Strong applicability-Because of the programmable software, the products can suit for different application scenario.
